Case Report

Volume 3, Number 5, October 2010, pages 216-218

Subcutaneous Emphysema, Pneumothorax and Pneumomediastinum Following Endoscopic Sphincterotomy

Leonardo L. Schiavona, b, Rodrigo A. Rodriguesa, Frank S. Nakaoa, Veruska O. Di Senaa, Angelo P. Ferraria, Ermelindo D. Libera, Jra

aFederal University of Sao Paulo, Gastroenterology Division, Hospital Sao Paulo, Sao Paulo, Brazil
bCorresponding author: Rua Durval Pires da Cunha, 210, Sambaqui, Florianopolis – SC, Brazil

Manuscript accepted for publication October 8, 2010
Short title: Post-ERCP Massive Gas Spread


Retroperitoneal perforation during therapeutic endoscopic retrograde cholangiopancreatography (ERCP) is uncommon and is usually manifested by abdominal pain, fever and leukocytosis. We report the case of a patient with post-ERCP subcutaneous emphysema, pneumomediastinum and pneumothorax treated conservatively. A 79-year-old woman with a diagnosis of choledocholitiasis was referred to our institution for an elective outpatient therapeutic ERCP. At the end of the procedure, subcutaneous emphysema was observed, and a thoracic computed tomography revealed a right pneumothorax and pneumomediastinum. Supportive care was instituted and she was discharged asymptomatic after 10 days of hospitalization. Subcutaneous emphysema, pneumothorax and pneumomediastinum are potencial complications of ERCP and sphincterotomy. We review the other cases previously reported and discuss the management.

Keywords: Subcutaneous emphysema; Pneumothorax; Pneumomediastinum; Sphincterotomy; Endoscopic retrograde cholangiopancreatography


Therapeutic endoscopic retrograde cholangiopancreatography (ERCP) is a well established method for treating recurrent or retained common bile duct stones. The reported rate of complications related to this procedure ranges from 0.8% to 45%, including pancreatitis, hemorrhage, perforation and cholangitis. The main risk factors for complication are difficult bile duct cannulation, cirrhosis, suspected sphincter of Oddi dysfunction, pre-cut technique and previous gastrointestinal surgery [1, 2]. Perforation during ERCP occurs in 2.1% of cases [3, 4]. Peritoneal perforation most frequently results from gastrointestinal wall injury during the procedure [2]. Retroperitoneal perforation is usually related to extensive sphincterotomy beyond the intramural portion of bile and pancreatic ducts. The classic features of retroperitoneal perforation include abdominal pain, fever and leukocytosis. However, most cases turn out well with minor clinical manifestations if an early diagnosis is made [5]. Subcutaneous emphysema, pneumomediastinum and pneumothorax as a result of retroperitoneal perforation after sphincterotomy are rarely reported complications [6-11]. We report the case of a patient with post-ERCP subcutaneous emphysema, pneumomediastinum and pneumothorax treated conservatively.

Case Report▴Top

A 79-year-old woman had a recent episode of jaundice and abdominal pain that resolved spontaneously. A transabdominal ultrasound revealed a dilated common hepatic duct with stone inside and she was referred to an elective outpatient ERCP because of choledocholitiasis. Her past medical history included diabetes and a cholecystectomy for cholelithiasis 16 years before. Examination was unremarkable. Aspartate aminotransferase, alanine aminotransferase, alkaline phosphatase, and bilirubin were within the normal range.

During the procedure, a peripapillary diverticula was present and a 8 mm single stone was seen in the common bile duct (Fig. 1). Bile duct diameter was 20mm. After a technically difficult sphincterotomy with a standard sphincterotome, the stone was successfully removed with standard ballon extraction technique. As soon as the procedure was finished, facial, cervical and thoracic subcutaneous emphysema were noticed. A chest x-ray revealed diffuse subcutaneous emphysema and a right-side pneumothorax (Fig. 2). These findings were confirmed by a thoracic computed tomography (CT) (Fig. 3), that also exhibited pneumomediastinum (Fig. 4). Abdominal CT was unremarkable. The patient was made NPO and intravenous administration of prophylactic metronidazole and cephtriaxone was initiated.

Figure 1.
Click for large image
Figure 1. Cholangiography showing a dilatated common bile duct with a single stone (black arrow).

Figure 2.
Click for large image
Figure 2. Chest x-ray showing diffuse subcutaneous emphysema (black arrows) and a right-side pneumothorax (white arrows).

Figure 3.
Click for large image
Figure 3. Thoracic computed tomography (CT) showing a small right-side pneumothorax (white arrows).

Figure 4.
Click for large image
Figure 4. Thoracic computed tomography (CT) showing pneumomediastinum (white arrows) and subcutaneous emphysema (black arrows).

Twelve hours after the procedure she presented with abdominal pain and fever. At physical examination, the abdomen was soft and tender and the subcutaneous emphysema had spontaneously resolved. Laboratory test results showed leucocytosis (13,000 cells/mm3) without left shift and blood cultures were negative. The patient remained clinically stable and on hospital day 4 she had no fever and white blood cell count returned to normal. Plain chest x-ray was normal with no evidence of subcutaneous emphysema, pneumothorax or pneumomediastinum. The abdominal pain resolved spontaneously after seven days and dietary intake was reestablished. The patient was discharged on hospital day 10.


There are a few reports of pneumomediastinum, pneumothorax and subcutaneous emphysema after upper endoscopy, colonoscopy and endoscopic sphincterotomy without evidence of perforation [12-18]. Interestingly, when perforation does occur, the extension of gaseous dissection does not appear to correlate with its size [4]. During ERCP, continuous air insufflation and repeated attempts to cannulate the papilla may increase the risk of perforation due to elevated pressure over the duodenal wall [9]. When a retroperitoneal perforation occurs, the free air flows from the duodenum to the right anterior pararenal space. In this case the air may dissecate the organs inferiorly and reaches the posterior pararenal compartment. From the posterior pararenal space the air can easily reach the diaphragmatic hiatus causing pneumomediastinum, pneumothorax or cervical subcutaneous emphysema [9-19].

The therapeutic approach in cases of retroperitoneal perforation is still a matter of discussion. In a series of cases reported by Martin et al, 11 patients with perforation after ERCP were followed. Ten patients had obstructive jaundice and one had acute pancreatitis. Sphincterotomy was performed in nine cases, two of which using the pre-cut technique. The patients were treated with antibiotics, NPO and naso-gastric tube. No further therapy was necessary and the admission time range from 2 to 10 days [5].

Complete resolution with conservative management was reported in four other cases of subcutaneous emphysema following ERCP [6-8, 11]. There are two reports of retroperitoneal perforation treated surgically [9, 10], and in one of these cases the perforation site was not identified during surgery [10].

In conclusion, subcutaneous emphysema, pneumothorax and pneumomediastinum are infrequent complications of ERCP and do not appear to change the prognosis of these subjects. CT is specially helpful for diagnosis and follow-up of these patients and conservative management with NPO, naso-gastric tube placement and antibiotic therapy seems to be an appropriate first-line approach.

  1. Vandervoort J, Soetikno RM, Tham TC, Wong RC, Ferrari AP Jr, Montes H, Roston AD, et al. Risk factors for complications after performance of ERCP. Gastrointest Endosc. 2002;56(5):652-656.
    pubmed doi
  2. Freeman ML. Adverse outcomes of ERCP. Gastrointest Endosc. 2002;56(6 Suppl):S273-282.
    pubmed doi
  3. Rabenstein T, Schneider HT, Hahn EG, Ell C. 25 years of endoscopic sphincterotomy in Erlangen: assessment of the experience in 3498 patients. Endoscopy. 1998;30(9):A194-201.
  4. Cotton PB, Lehman G, Vennes J, Geenen JE, Russell RC, Meyers WC, Liguory C, et al. Endoscopic sphincterotomy complications and their management: an attempt at consensus. Gastrointest Endosc. 1991;37(3):383-393.
    pubmed doi
  5. Martin DF, Tweedle DE. Retroperitoneal perforation during ERCP and endoscopic sphincterotomy: causes, clinical features and management. Endoscopy. 1990;22(4):174-175.
    pubmed doi
  6. Ciaccia D, Branch MS, Baillie J. Pneumomediastinum after endoscopic sphincterotomy. Am J Gastroenterol. 1995;90(3):475-477.
  7. Evrard S, Mendoza L, Mutter D, Vetter D, Marescaux J. Massive gas spread through a duodenal perforation after endoscopic sphincterotomy. Gastrointest Endosc. 1993;39(6):817-818.
    pubmed doi
  8. Ibrarullah, Saxena R, Agarwal DK, Saraswat VA. Massive subcutaneous and mediastinal emphysema due to duodenal perforation following endoscopic sphincterotomy. Indian J Gastroenterol. 1993;12(1):21-22.
  9. Savides T, Sherman S, Kadell B, Cryer H, Derezin M. Bilateral pneumothoraces and subcutaneous emphysema after endoscopic sphincterotomy. Gastrointest Endosc. 1993;39(6):814-817.
    pubmed doi
  10. Gya D, Sali A, Angus D. Subcutaneous emphysema and pneumothorax following endoscopic sphincterotomy. Aust N Z J Surg. 1989;59(11):900-902.
    pubmed doi
  11. Colemont LJ, Pelckmans PA, Moorkens GH, Van Maercke YM. Unilateral periorbital emphysema: an unusual complication of endoscopic papillotomy. Gastrointest Endosc. 1988;34(6):473-475.
    pubmed doi
  12. Katz D, Cano R, Antonelle M. Benign air dissection of the esophagus and stomach at fiberesophagoscopy. Gastrointest Endosc. 1972;19(2):72-74.
    pubmed doi
  13. Allan RN, Smallwood CJ. Pneumomediastinum and subcutaneous emphysema after perforation of the duodenum during gastroscopy. Br J Surg. 1973;60(2):156-157.
    pubmed doi
  14. Amshel AL, Shonberg IL, Gopal KA. Retroperitoneal and mediastinal emphysema as a complication of colonoscopy. Dis Colon Rectum. 1982;25(2):167-168.
    pubmed doi
  15. Humphreys F, Hewetson KA, Dellipiani AW. Massive subcutaneous emphysema following colonoscopy. Endoscopy. 1984;16(4):160-161.
    pubmed doi
  16. Schmidt G, Borsch G, Wegener M. Subcutaneous emphysema and pneumothorax complicating diagnostic colonoscopy. Dis Colon Rectum. 1986;29(2):136-138.
    pubmed doi
  17. Girardi A, Piazza I, Giunta G, Pappagallo G. Retroperitoneal, mediastinal and subcutaneous emphysema as a complication of routine upper gastrointestinal endoscopy. Endoscopy. 1990;22(2):83-84.
    pubmed doi
  18. Bakker J, van Kersen F, Bellaar Spruyt J. Pneumopericardium and pneumomediastinum after polypectomy. Endoscopy. 1991;23(1):46-47.
    pubmed doi
  19. Maunder RJ, Pierson DJ, Hudson LD. Subcutaneous and mediastinal emphysema. Pathophysiology, diagnosis, and management. Arch Intern Med. 1984;144(7):1447-1453.
    pubmed doi
